CRT-196/67

• Maximum Reel Weight*

  20,000 lbs., fully loaded, 3 in. reel shaft

• Maximum Reel Size

  96 in. OD x 67 in. wide

• Reel Shaft Diameter

  2‑5/8 in., 1 ea., and 3 in., 1 ea., included

• Reel Brake

  20 in. dia. disc, Al-bronze

• Brake Control

  T-handle, manually adjusted

• Frame Construction

  Steel tubing, continuous-weld

• Length, overall, nom.

  16 ft., 8 in.

• Width, overall, nom.

  8 ft., 6 in.

• Height, overall, nom.

  9 ft., 4 in.

• Weight*

  6,500 lbs.

• GVWR

  30,000 lbs.

• Suspension

  Leaf‑spring

• Axle Configuration

  Tandem

• Wheel Configuration & Tires

  Single, 215/75R17.5H

• Brakes, trailer

  Electric (air brakes with ABS optional)

• Front/Nose Jack

  Drop-leg with pin & shoe

• Rear Jacks

  Drop-leg with pin & shoe, (2)

• Towing Attachment

  3 in. adjustable pintle eye

• Safety Chains

  2 ea., with hook

• Lights, navigation

  US DOT, LED, 12 VDC

• Grounding

  3/4 in. dia. copper-clad steel ground loops, 4 ea.

• Paint

  S+R White

• Height with 96 in. Reel

  11 ft., 7 in.
