PTV-6013 Puller Tensioner V-Groove Reconductorer
13,000 LBS. BULLWHEEL PULLER TENSIONER V-GROOVE RECONDUCTORER
The PTV 6013 is a puller tensioner and reconductorer in a single unit delivering 13,000 lb of pulling force and tensioning force from 500 lb. to 8,000 lb. Included is a self-loading reel stand capable of supporting a 96H inch by 67W inch reel, up to 18,000 lb. The 60 inch bullwheels provide constant tension and handle transmission class conductors at a maximum speed of 4 mph. This pulling and tensioning equipment also features a reconductoring 60-inch V-groove application for “wrecking-out” old conductor.
13,000 lbs. per bullwheel set
8,000 lbs. per bullwheel set / Low force mode: min. 500 lbs., max. 2,900 lbs. / High force mode: min. 1,900 lbs.,max. 8,000 lbs.
Maximum Line Speed
Pulling: 4 mph
Rope Reel Capacities
96 in. flange, 67 in. width
Reel Shaft Diameter
3 in. (opt. adapters for up to 5 in.)
Direct drive: hydraulic motor, bullwheel
Drive System Engine
174 Hp diesel, turbo-charged, CAT C4.4 ACERT L4,
T4 final with Webasto Arctic Pack
Nominal Diameter: 60 in.
Bullwheel Count: 2 (1 pair)
Bullwheel Groove Count: 5 per
Bullwheel Groove Radius: 1 in.
Groove Lining: Molded neoprene
V-Groove Max. Capacity: 2 in.
V-Groove Min. Capacity: 5/8 in.
17,000 ft. of 20 mm Anti-Twist Steel
Cable / 17,800 lbs. total weight
Rope: 17,500 ft. of .84 in. Unitrex / 17,800 lbs. total weight
Hydraulic-applied, automatic, per operator setting
ISO Grade 32
Solar Battery Charger
